PBLS6002D-QX
Nexperia USA Inc.
Package: Tape & Reel (TR)
Description: TRANS PREBIAS 1NPN 1PNP 6-TSOP
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Part Status | Active |
|---|---|
| Power - Max | 200mW, 250mW |
| Mounting Type | Surface Mount |
| Package / Case | SC-74, SOT-457 |
| Transistor Type | 1 NPN Pre-Biased, 1 PNP |
| Resistor - Base (R1) | 4.7kOhms |
| Frequency - Transition | 185MHz |
| Supplier Device Package | 6-TSOP |
| Resistor - Emitter Base (R2) | 4.7kOhms |
| Vce Saturation (Max) @ Ib, Ic | 150mV @ 500μA, 10mA / 340mV @ 100mA, 1A |
| Current - Collector (Ic) (Max) | 100mA, 700mA |
| Current - Collector Cutoff (Max) | 1μA, 100nA |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 30 @ 20mA, 5V / 200 @ 1mA, 5V |
| Voltage - Collector Emitter Breakdown (Max) | 50V, 60V |
