PMEG4050CEPX
Nexperia USA Inc.
Package: Cut Tape (CT)
Description: PMEG4050CEP/SOD128/FLATPOWER
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | - |
|---|---|
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Technology | Schottky |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Qualification | - |
| Package / Case | SOD-128 |
| Capacitance @ Vr, F | 250pF @ 1V, 1MHz |
| Supplier Device Package | SOD-128/CFP5 |
| Reverse Recovery Time (trr) | 8.9 ns |
| Current - Reverse Leakage @ Vr | 100 μA @ 40 V |
| Voltage - DC Reverse (Vr) (Max) | 40 V |
| Current - Average Rectified (Io) | 5A |
| Operating Temperature - Junction | 175°C |
| Voltage - Forward (Vf) (Max) @ If | 620 mV @ 5 A |
