ULN2004ANE4
Texas Instruments
Package: Tube
Description: TRANS 7NPN DARL 50V 500MA 16PDIP
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Part Status | Obsolete |
|---|---|
| Power - Max | - |
| Mounting Type | Through Hole |
| Package / Case | 16-DIP (0.300", 7.62mm) |
| Transistor Type | 7 NPN Darlington |
| Operating Temperature | 150°C (TJ) |
| Frequency - Transition | - |
| Supplier Device Package | 16-PDIP |
| Vce Saturation (Max) @ Ib, Ic | 1.6V @ 500μA, 350mA |
| Current - Collector (Ic) (Max) | 500mA |
| Current - Collector Cutoff (Max) | 50μA |
| DC Current Gain (hFE) (Min) @ Ic, Vce | - |
| Voltage - Collector Emitter Breakdown (Max) | 50V |
