ULS2801R-883
Allegro MicroSystems
Package: Bulk
Description: TRANS 8NPN DARL 50V 18CERDIP
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Part Status | Obsolete |
|---|---|
| Power - Max | 1W |
| Mounting Type | Through Hole |
| Package / Case | 18-CDIP (0.300", 7.62mm) |
| Transistor Type | 8 NPN Darlington |
| Operating Temperature | -55°C ~ 125°C (TA) |
| Frequency - Transition | - |
| Supplier Device Package | 18-CERDIP |
| Vce Saturation (Max) @ Ib, Ic | 1.6V @ 500μA, 350mA |
| Current - Collector (Ic) (Max) | 600mA |
| Current - Collector Cutoff (Max) | 100μA |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 1000 @ 350mA, 2V |
| Voltage - Collector Emitter Breakdown (Max) | 50V |
