NE68519-T1-A
CEL
Package: Tape & Reel (TR)
Description: RF TRANS NPN 6V 12GHZ SC-75
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Gain | 8.5dB |
|---|---|
| Part Status | Obsolete |
| Power - Max | 125mW |
| Mounting Type | Surface Mount |
| Package / Case | SC-75, SOT-416 |
| Transistor Type | NPN |
| Operating Temperature | 150°C (TJ) |
| Frequency - Transition | 12GHz |
| Supplier Device Package | SC-75 (USM) |
| Noise Figure (dB Typ @ f) | 1.5dB @ 2GHz |
| Current - Collector (Ic) (Max) | 30mA |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 75 @ 10mA, 3V |
| Voltage - Collector Emitter Breakdown (Max) | 6V |
