NSVDP301MX2WT5G
onsemi
Package: Cut Tape (CT)
Description: RF DIODE PIN 80V 2X3DFN
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | Automotive |
|---|---|
| Diode Type | PIN - Single |
| Part Status | Active |
| Current - Max | 100 mA |
| Qualification | AEC-Q101 |
| Package / Case | 2-XDFN |
| Resistance @ If, F | 1.3Ohm @ 10mA, 100MHz |
| Capacitance @ Vr, F | 0.33pF @ 0V, 1MHz |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Supplier Device Package | 2-X2DFNW (1x0.6) |
| Voltage - Peak Reverse (Max) | 80V |
