NSVF5488SKT3G
onsemi
Package: Cut Tape (CT)
Description: RF TRANS NPN 10V 7GHZ SOT-623
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Gain | 12dB |
|---|---|
| Grade | Automotive |
| Part Status | Active |
| Power - Max | 100mW |
| Mounting Type | Surface Mount |
| Qualification | AEC-Q101 |
| Package / Case | SOT-623F |
| Transistor Type | NPN |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Frequency - Transition | 7GHz |
| Supplier Device Package | SOT-623/SSFP |
| Noise Figure (dB Typ @ f) | 1dB @ 1GHz |
| Current - Collector (Ic) (Max) | 70mA |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 90 @ 20mA, 5V |
| Voltage - Collector Emitter Breakdown (Max) | 10V |
