STP802U2SRP
IXYS
Package: Cut Tape (CT)
Description: SCR MODULE 800V 0.6A 8-SOIC
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Structure | Independent - All SCRs |
|---|---|
| Part Status | Active |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Voltage - Off State | 800 V |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Number of SCRs, Diodes | 2 SCRs |
| Current - Hold (Ih) (Max) | 3 mA |
| Current - Gate Trigger (Igt) (Max) | 100 μA |
| Voltage - Gate Trigger (Vgt) (Max) | 800 mV |
| Current - On State (It (RMS)) (Max) | 0.6 A |
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 20A, 24A |
