STTH60400SA1
STMicroelectronics
Package: Strip
Description: RAD-HARD 60 A - 400 V ULTRAFAST
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | - |
|---|---|
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Technology | Standard |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Qualification | - |
| Package / Case | 3-SMD, No Lead |
| Capacitance @ Vr, F | 250pF @ 10V, 1MHz |
| Supplier Device Package | SMD1 |
| Reverse Recovery Time (trr) | 80 ns |
| Current - Reverse Leakage @ Vr | 20 μA @ 400 V |
| Voltage - DC Reverse (Vr) (Max) | 400 V |
| Current - Average Rectified (Io) | 60A |
| Operating Temperature - Junction | -65°C ~ 175°C |
| Voltage - Forward (Vf) (Max) @ If | 1.3 V @ 60 A |
