AIKQB200N75CP2ALSA1
Infineon Technologies
Package: Tube
Description: AIKQB200N75CP2ALSA1
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | Automotive |
|---|---|
| IGBT Type | - |
| Input Type | Standard |
| Gate Charge | 1.256 μC |
| Part Status | Active |
| Power - Max | 938 W |
| Mounting Type | Through Hole |
| Qualification | AEC-Q101 |
| Package / Case | TO-247-3 |
| Test Condition | 470V, 200A, 5Ohm, 15V |
| Switching Energy | 15.3mJ (on), 7mJ (off) |
| Td (on/off) @ 25°C | 89ns/266ns |
| Operating Temperature | -40°C ~ 175°C (TJ) |
| Supplier Device Package | PG-TO247-3-51 |
| Vce(on) (Max) @ Vge, Ic | 1.65V @ 15V, 200A |
| Current - Collector (Ic) (Max) | 250 A |
| Current - Collector Pulsed (Icm) | 600 A |
| Voltage - Collector Emitter Breakdown (Max) | 750 V |
