RGS50TSX2DGC11
ROHM Semiconductor
Package: Tube
Description: IGBT TRENCH FS 1200V 50A TO-247N
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| IGBT Type | Trench Field Stop |
|---|---|
| Input Type | Standard |
| Gate Charge | 67 nC |
| Part Status | Active |
| Power - Max | 395 W |
| Mounting Type | Through Hole |
| Package / Case | TO-247-3 |
| Test Condition | 600V, 25A, 10Ohm, 15V |
| Switching Energy | 1.4mJ (on), 1.65mJ (off) |
| Td (on/off) @ 25°C | 37ns/140ns |
| Operating Temperature | -40°C ~ 175°C (TJ) |
| Supplier Device Package | TO-247N |
| Vce(on) (Max) @ Vge, Ic | 2.1V @ 15V, 25A |
| Reverse Recovery Time (trr) | 182 ns |
| Current - Collector (Ic) (Max) | 50 A |
| Current - Collector Pulsed (Icm) | 75 A |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
