AOT10B60M1
Alpha & Omega Semiconductor Inc.
Package: Tape & Reel (TR)
Description: IGBT 600V 20A TO-220
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| IGBT Type | - |
|---|---|
| Input Type | Standard |
| Gate Charge | 14 nC |
| Part Status | Not For New Designs |
| Power - Max | 83 W |
| Mounting Type | Through Hole |
| Package / Case | TO-220-3 |
| Test Condition | 400V, 10A, 30Ohm, 15V |
| Switching Energy | 190μJ (on), 140μJ (off) |
| Td (on/off) @ 25°C | 5.5ns/61ns |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Supplier Device Package | TO-220 |
| Vce(on) (Max) @ Vge, Ic | 2.9V @ 15V, 10A |
| Current - Collector (Ic) (Max) | 20 A |
| Current - Collector Pulsed (Icm) | 25 A |
| Voltage - Collector Emitter Breakdown (Max) | 600 V |
