BAT54AWTHQ-TP
MCC (Micro Commercial Components)
Package: Tape & Reel (TR)
Description: DIODE ARR SCHOT 30V 200MA SOT323
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | Automotive |
|---|---|
| Speed | Small Signal =< 200mA (Io), Any Speed |
| Technology | Schottky |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Qualification | AEC-Q101 |
| Package / Case | SC-70, SOT-323 |
| Diode Configuration | 1 Pair Common Anode |
| Supplier Device Package | SOT-323 |
| Reverse Recovery Time (trr) | 5 ns |
| Current - Reverse Leakage @ Vr | 2 μA @ 25 V |
| Voltage - DC Reverse (Vr) (Max) | 30 V |
| Operating Temperature - Junction | -55°C ~ 150°C |
| Voltage - Forward (Vf) (Max) @ If | 1 V @ 100 mA |
| Current - Average Rectified (Io) (per Diode) | 200mA |
