NTMFD5C672NLT1G
onsemi
Package: Cut Tape (CT)
Description: MOSFET 2N-CH 60V 12A 8DFN
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | - |
|---|---|
| Technology | MOSFET (Metal Oxide) |
| FET Feature | - |
| Part Status | Active |
| Power - Max | 3.1W (Ta), 45W (Tc) |
| Configuration | 2 N-Channel (Dual) |
| Mounting Type | Surface Mount |
| Qualification | - |
| Package / Case | 8-PowerTDFN |
| Vgs(th) (Max) @ Id | 2.2V @ 30μA |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Rds On (Max) @ Id, Vgs | 11.9mOhm @ 10A, 10V |
| Supplier Device Package | 8-DFN (5x6) Dual Flag (SO8FL-Dual) |
| Gate Charge (Qg) (Max) @ Vgs | 12.3nC @ 10V |
| Drain to Source Voltage (Vdss) | 60V |
| Input Capacitance (Ciss) (Max) @ Vds | 793pF @ 25V |
| Current - Continuous Drain (Id) @ 25°C | 12A (Ta), 49A (Tc) |
