2SC6023-TR-E
onsemi
Package: Bulk
Description: RF TRANS NPN 3.5V 14.5GHZ 4-MCP
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Gain | 9.5dB ~ 11dB |
|---|---|
| Part Status | Obsolete |
| Power - Max | 120mW |
| Mounting Type | Surface Mount |
| Package / Case | SC-82A, SOT-343 |
| Transistor Type | NPN |
| Frequency - Transition | 14.5GHz |
| Supplier Device Package | 4-MCP |
| Noise Figure (dB Typ @ f) | 1.2dB @ 2GHz |
| Current - Collector (Ic) (Max) | 35mA |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 80 @ 15mA, 3V |
| Voltage - Collector Emitter Breakdown (Max) | 3.5V |
