SE80PWTLK-M3/I
Vishay General Semiconductor - Diodes Division
Package: Cut Tape (CT)
Description: RECTIFIER, STANDARD RECOVERY, 8A
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | - |
|---|---|
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Technology | Standard |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Qualification | - |
| Package / Case | TO-252-3, DPAK (2 Leads + Tab), SC-63 |
| Capacitance @ Vr, F | 58pF @ 4V, 1MHz |
| Supplier Device Package | SlimDPAK |
| Reverse Recovery Time (trr) | 360 ns |
| Current - Reverse Leakage @ Vr | 5 μA @ 800 V |
| Voltage - DC Reverse (Vr) (Max) | 800 V |
| Current - Average Rectified (Io) | 2.5A |
| Operating Temperature - Junction | -55°C ~ 175°C |
| Voltage - Forward (Vf) (Max) @ If | 1 V @ 8 A |
